With three dedicated Aerofoil™ Profile bass drivers, a Continuum™ cone, and a solid body tweeter housing on top, 702 S2 brings the goosebump-inducing clarity and detail of studio-quality sound to your home audio set-up.
* Satin White/Rosenut Color , Preordering. Please Contact Us on 77777003 or by email: info@elyqq.com
* Price is for a single unit , Must order 2 pieces
Goosebumps guaranteed
Music. Movies. Television. 702 S2 promises to transform your living room into a haven of high-quality sound, thanks to its studio-grade technologies trickled down from the 800 Series Diamond.
Truly amazing sound
Voices and instruments are delivered with purity and precision, thanks to the smooth, accurate Continuum™ cone midrange driver.
Clean and clear
The midrange drivers in these floorstanders feature decoupled design, adapted from a similar system in the 800 Series Diamond. Decoupling reduces cabinet coloration, and boosts midrange clarity.
A triumph of science
Developed using advanced computer modeling techniques, the Aerofoil™ Profile bass cone has variable thickness, providing stiffness and rigidity where it’s needed most. The result: deep and dynamic bass.
Model
702 S2
Description
3-way vented-box system
Features
Decoupled Carbon Dome tweeter
Solid Body Tweeter-on-Top
Continuum™ cone FST™ midrange
Decoupled midrange
Aerofoil™ Profile bass cones
Flowport™
Drive units
1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
1x ø150mm (6 in) Continuum cone FST midrange
3x ø165mm (6.5 in) Aerofoil Profile bass
Frequency range
-6dB at 28Hz and 33kHz
Frequency response
46Hz - 28kHz ±3dB
Sensitivity
90dB spl (2.83Vrms, 1m)
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m)
<1% 86Hz - 28kHz
<0.5% 110Hz - 20kHz
Nominal impedance
8Ω (minimum 3.1Ω)
Recommended amplifier power
30W - 300W into 8Ω on unclipped programme
Dimensions
Height: 994mm (39 in) cabinet only 1087mm (42.8 in) including tweeter and plinth
Width: 200mm (7.9 in) cabinet only 366mm (14.4 in) including plinth
Depth: 337mm (13.3 in) cabinet only 364mm (14.3 in) inc. grille and terminals 452mm including plinth
Net weight
29.5kg (65 lb)
Cabinet finishes
Gloss Black
Satin White
Rosenut
Grille finishes
Black
Grey (Satin White only)
